KLTV Series
Bare Chassis
  • youtube
  • english
  • french
  • spanish
  • arabic
  • Kia developed KLTV Bare Chassis Vehicle based on
    long-accumulated technology and infrastructure for commercial and
    Military vehicles.
    This KLTV Bare Chassis vehicle can be easily modified as specialized vehicles on the basis of diverse customer requirements.

    • 225-HP diesel engine

      A high-performance eco-friendly diesel engine which boasts strong horsepower and torque optimized for military purpose with its unyielding power, excellent fuel economy and super durability.

    • 8-Speed Automatic transmission

      Enhanced fuel economy, shift quality and driving performance with multi - speeds transmission.

    • Air conditioner

      Provides a pleasant environment to riders all the time and secures visibility of a driver by defrosting the windshield.

    • All wheel drive (AWD)

      The all wheel drive function is applied for improving tracking and hauling power, steering capability and stability, and off-road driving power.

    • Independent suspension

      Ensuring superb riding comfort and stable maneuverability as 4 wheels are independently operated during driving on rough terrain, and exerting strong driving and braking power by enhancing the traction with the road surface.

    • Hub reduction axle

      Raising the ground clearance of the body by applying the hub reduction portal axle, and enhancing the off-road driving capability on unpaved roads/rough terrains with additional reduction of the gear ratio for the increase of torque.

    • 4 channel ABS

      By judging the amount of slipping of wheels and controlling the brake pressure, maintaining the stability of the vehicle and shortening the braking distance.

    KLTV Series Bare Chassis
    Type Technical Data
    Standard Wheel Base Long Wheel Base
    Overall length mm 4,900 6,000
    Overall width mm 2,195
    Max. GVW kg 5,700 7,000
    Ground Clearance mm 410
    Engine Power ps@rpm 225@3,200
    Engine Torque kg·m@rpm 51@1,750
    Max. Speed km/h 130
    Gradient % 60
    Min Turning Radius m 7.8 9.2
    Fording Depth mm 760
    Cruising Range km 640
    * All information is subject to change without notice according to any further improvements or operational environments.
    * The new camouflage color of KLTV vehicles has been reflected as of 2019
