KM450 Series
Cargo Truck
  • youtube
  • english
  • french
  • spanish
  • arabic
  • Kia developed its Light Tactical Vehicle with great mobility and high survivability that best suits a changed battle environment and efficient tactical operations based on its long-accumulated technology and infrastructure for commercial and military vehicles.
    This KLTV151 is a flexible tactical vehicle with high survivability and mobility for successful commanding missions.

    • Engine/Power train and frame

      Environmentally friendly 139 hp diesel engine, and optimized power train with 5 Speed manual transmission and 2 Speed transfer case
      Configuring optimal frame of vehicle for mounting chassis system

    • Deck

      Loading capacity: 6㎥ (2,358mm x 1,776mm)
      Loading weight: 2,500kg (on pavement road)
      Folding seats: Accommodates 12 armored soldiers

    • Utilization for diverse purposes

      Detachable soft-top over cabin, and water-proof tarpaulin (support) over rear deck
      Folding windshield for increasing versatility on the battlefield

    • Differential locking device (NSD)

      This is mounted on the differential on the rear axles for ensuring driving on any surface conditions including damp ground and/or icy and sandy surfaces.

    • Hauling system

      The hauling hook is installed on the rear of vehicle for connecting the trailer to the vehicle (hauling weight on a paved road: 2,000 kg)
      Receptacle for supplying 24-V power

    • Winch (optional)

      Remote control power-driven winch mounted on the front of vehicle
      Maximum hauling power: 3,600 kg or more

    KM450 Series Cargo Truck
    Type Technical Data
    Overall length mm 5,460
    Overall width mm 2,180
    Overall height mm 2,450
    GVW kg 5,650
    Max. Speed km/h 104
    Max. Horsepower kg·m@rpm 139@2,900
    Max. Torque kg·m@rpm 38@1,600
    Gradeability % 60
    Fording Depth mm 760
    Ground Clearance mm 254
    Min. Turning Radius m 8.5
    Range km 700
    * All information is subject to change without notice according to any further improvements or operational environments.
